ABDIEL

Fleet

Royal Navy

Ship Type

Minelayer

Nickname

–

Ship Class

Marksman

Grouping

Attached

Command

Grand Fleet

Builder's Yard

Cammell Laird at Birkenhead

Budget Year

–

Construction Notes

–

Date Laid Down

06.05.1915

Launch Date

12.10.1915

Completed date

–

Commission date

26.03.1916

Year laid down

–

Year launched

–

Year completed

–

Commission Year

–

Pennant No

–

Photo Details

–

Sister ships

–

Eventual Fate

Scrapped 1935

Jutland result

Sent ahead by JRJ to mine the entrance to the Horns Reef. SMS Ostrfriesland struck a mine laid by the Abdiel on May 4th.

Ready for action after dock repairs

–

Commander

Commander Berwick Curtis

Noteable Officers

–

Crew complement

104

Officers

–

Ratings

–

Killed

–

Wounded

–

Prisoners

–

Displacement full Load (tons)

1,700

Artefacts Data

–

Ship's Model

–

Length (ft)

324.1

Length (mtrs)

99.01 m

Beam (ft)

31.9

Beam (mtrs)

9.68

Draught (ft)

Draught (mtrs)

3.66

Max. Speed (knots)

Range (miles)

4,940 15kts

Range (kilometres)

–

Fuel

–

Propulsion

3 shaft, Parsons turbine. 4 Yarrow boilers yielding 36,000 shp

Armour Main Belt

–

Deck Armour

–

Turret Armour IN CM

–

Conning Tower Armour

–

Barbette Armour

–

Weight of armour

–

Armour / Displacement Ratio

–

Watertight compartments

–

General Notes

–

Fire Control Table

–

Fire Control - Clock

–

Primary Gun calibre

–

No. Primary Turrets

–

Guns (No.barrels)

–

Primary gun layout

–

Rounds per main gun

–

Effective broadside guns

–

Primary shell Weight (inches or cm)

–

Primary Broadside Weight

–

Secondary Gun Calibre

–

Guns (No.barrels) 2

–

Rounds per secondary

–

Other Armament

2 x QF Mk IV 4" guns, 2x 2 pdr Pom Pom Mk II AA.

Elevation (degrees)

–

Gunnery Range (yards)

–

Gunnery Range (metres)

–

Rate of Fire (rds per minute)

–

Shells expended Main

–

Mines dropped

–

Shells expended Secondary

–

Torpedoes fired

–

Gunnery Notes

–

Torpedo Type IN

–

No. tubes

–

Torpedo Type MM

–

No. Mines

Torpedo Notes

–
